CAT6a SFTP KEYSTONE JACK:
The Cat6a SFTP Keystone Jack is a high-performance shielded modular outlet designed for terminating Category 6a SFTP (Shielded Foiled Twisted Pair) cables in structured cabling systems. It is Backwards compatible with Cat5e to Cat7.
It supports 10 Gigabit Ethernet transmissions up to 600-900 MHz bandwidth and provides superior protection against electromagnetic interference (EMI) and alien crosstalk. The fully shielded metal housing ensures 360° grounding continuity, making it ideal for high-density data centers and industrial networking environments.
Features:
- RJ45 8P8C female interface (Shielded)
- Designed for Cat6A SFTP cables (22–26AWG solid conductors)
- Bandwidth up to 600-900 MHz
- Supports 10GBASE-T (10 Gbps) up to 100 meters
- Individual pair foil support + overall shield grounding
- 360° metal shielding for enhanced EMI protection
- Tool-less termination
- Compatible with T568A & T568B wiring standards
- Snap-in keystone design for faceplates and patch panels
Technical Specifications:
| Cable Category | Cat6a |
| Shielding | SFTP |
| Termination Type | Tool-less |
| Housing Material | Shielded metal body |
| Contact Material | Gold-plated contacts |
| Compatible Wire Gauge | 22–26 AWG |
| Durability | ≥750 mating cycles |
| Operating Temperature | -20°C to +60°C |
| Bandwidth | 600–900 MHz |
